Developed exclusively for DJI FlyCart delivery drones, this high-rise fire-fighting payload combines two core functions: high-pressure fire suppression and tempered glass breaking.
Built with aviation-grade modular quick connectors, the fire assembly can be mounted in under 30 seconds. It comes standard with a custom 40mm fire hose that delivers vertical firefighting reach up to 30 meters, surpassing height limits of conventional fire trucks. Equipped with a dual-shot window-breaking launcher, it pierces double-layer 16mm vacuum tempered glass and handles two firefighting missions per flight for rapid fire knockdown.
It deploys fast on a minimal 6m×6m footprint, ideal for fire emergencies in narrow old residential alleys and wooded areas around buildings, delivering a highly mobile solution for confined-space fire response.
Product Specifications
Product Specifications
Model No.: BWG-40
Overall Dimensions: 2000mm × 52mm × 130mm
Total Weight: 3.0kg (quick-release assembly included)
Mounting Method: Quick release
Spray Angle: Manually adjustable
Peak Power Consumption: ≤15W
Operating Temperature: -20℃ ~ 45℃
Nozzle Bore Diameter: 20mm
Fire Hose Diameter: 40mm
Firing Mode: Single-shot / Dual-shot
Effective Window-Breaking Distance: 10m ~ 15m
Aiming System: Laser sighting
Compatible Extinguishing Agents: Fire foam / Aqueous fire suppressant
Recommended Operating Altitude: 0m ~ 70m for FC100; 0m ~ 150m for FC200
Matching Hose Length: 90m for FC100; 150m for FC200
Effective Water Jet Range: 10m ~ 15m
Working Pressure Resistance: 2.5MPa
Burst Pressure: 3.2MPa
Communication Port: DJI FlyCart 100 E-Port Lite
Power Supply Port: FlyCart 100 aerial hoist system interface
Control Protocol: PSDK
