The Six-Channel Launcher is a multi-scenario mission payload purpose-built for the DJI M400 UAV platform. Each channel is equipped with an independent shock-absorbing structure, significantly enhancing overall system stability. The UAV automatically recognizes the launcher upon power-up, ready to deploy with a full load of six rounds. It supports multiple ammunition types including smoke grenades, tear gas grenades, and stun grenades, with one-touch channel-specific arming to fundamentally prevent accidental discharge and collateral injury. Engineered with an IP45 protection rating, real-time status feedback, and a laser-assisted aiming system, it is ideally suited for multi-scenario operations including law enforcement, security patrol, and emergency response, delivering a safe, stable, and precision solution for professional applications.

Specifications

Product Material: Carbon fiber + Aviation-grade aluminum + Stainless steel Product Dimensions: 139 mm × 111 mm × 178 mm Product Weight: Approx. 0.87 kg Recoil Force: ≤1 kg System Power: ≤30 W Operating Temperature: -20°C to 45°C Status Feedback: Real-time status transmission for each channel Safety Device: Safety switch Supported Ammunition Types: 38 mm smoke grenades / tear gas grenades / stun grenades, etc. Mounting Method: Quick-release, vertical downward orientation Mounting Position: Under-fuselage Protection Rating: IP45 Safety Modes: Device lock / Load detection / Power-on detection Protection Modes: Firing detection / Anti-drop design Auxiliary Function: Laser-assisted aiming Payload Interface: SKYPORT V2.0 Control Method: DJI Pilot 2
