The Matrix Light is a high-power nighttime illumination payload purpose-built for professional UAV applications. Featuring 18 high-output LEDs, it delivers an impressive 20,000 lm of brightness at 120 W, producing daylight-grade illumination. The entire unit weighs just 0.26 kg — an ultra-lightweight design that imposes virtually no burden on the UAV’s payload capacity, preserving both flight endurance and operational capability. Equipped with an intelligent temperature-controlled thermal protection system, the light automatically restricts brightness when the housing temperature exceeds 80°C, and shuts off automatically above 85°C, effectively preventing overheating damage and extending the lifespan of the fixture. It supports 0–100% stepless brightness adjustment, allowing users to freely tailor illumination intensity to the operational scenario. A soft-start design ensures brightness ramps up smoothly upon power-up, eliminating instantaneous high-current surges that could compromise circuitry and the light source. Widely deployed in nighttime emergency rescue, power line inspection, police patrol, and construction lighting scenarios, it delivers stable, safe, and efficient illumination support for nighttime operations.

Specifications

Dimensions: 205 mm × 35 mm × 28 mm Weight: Approx. 0.26 kg Supply Voltage: 48 V – 80 V Peak Power: 18 LEDs, 120 W Operating Temperature: -20°C to 45°C Brightness: 20,000 lm Soft Start: 3 s soft-start duration (direct maximum power output without control signal) Thermal Protection: Brightness limited to 10% above 80°C; automatic shutoff above 85°C Dimming Function: Brightness adjustment range 0 – 100% Control Method: PWM
