The High-Altitude Facade Cleaning Spray Lance Kit (Dual-Nozzle) is a dedicated facade cleaning payload purpose-built for the DJI M400 enterprise UAV. Featuring a lightweight carbon fiber extended-lance design, the entire unit weighs just 1.15 kg and mounts securely under the fuselage via bolt fixation. Compatible with the DJI M400 E-Port V interface, it connects directly to DJI Pilot 2 for control through the PSDK protocol. Equipped with a dual-nozzle system, the kit supports one-touch switching between high-pressure water jet and foam cleaning modes, delivering a spray distance of 7–10 meters. The integrated cross-oscillation mechanism enables a ±30° lateral sweep, effectively covering facades of varying orientations. With a recommended flight altitude of ≤120 m and a 20 MPa high-pressure water hose rated for aerial cleaning demands, the system is widely suited for high-altitude operations including glass curtain wall cleaning, exterior wall tile cleaning, and billboard cleaning. It delivers a safe, efficient UAV-based cleaning solution for high-rise building exterior maintenance.

Compatible Aircraft: M400

Specifications

Spray Lance Dimensions: 970 mm × 94 mm × 131 mm Total Weight: Approx. 1.4 kg Mounting Method: Quick-release Mounting Position: Under-fuselage Control Method: PSDK (DJI Pilot 2) Supply Voltage: 24 V Peak Power: ≤30 W Operating Temperature: -20°C to 45°C Spray Distance: 7 – 10 m Recommended Flight Altitude: ≤120 m Communication & Power Supply Interface: DJI M400 E-Port V interface Water Hose Dimensions: Inner diameter 4 mm, outer diameter 8.6 mm Water Hose Pressure Rating: 20 MPa Cleaning Modes: Cross-oscillation ±30° lateral sweep; Fixed angle forward-facing / left-facing / right-facing / upward / downward; In-flight switching between cylindrical clean-water nozzle and foam nozzle
