This product is a multi-functional payload device compatible with a wide range of UAV platforms. It integrates loudspeaker, illumination, red-and-blue warning lights, cargo release, and laser guidance functions, along with firefighting bomb delivery capability. Featuring quick-release mounting, remote control operation, and real-time status feedback, the system efficiently meets the multi-mission demands of firefighting, rescue, and other operational scenarios, unlocking new possibilities for industry users.

Compatible Aircraft: M400

Specifications

Product Name: All-in-One Payload Model: WZH-2 Product Dimensions: Nose at 0°: 187 mm (L) × 136 mm (W) × 154 mm (H); Nose at 90°: 155 mm (L) × 136 mm (W) × 187 mm (H) Product Weight: 820 g Operating Voltage: 24 V Operating Temperature: -20°C to 45°C Control Distance: Consistent with link equipment range Communication Interface / Method: Ethernet port Control Method: Intelligent Payload App Peak Power: ≤80 W Functional Modules: ① Audio ② Illumination ③ Red & Blue Warning Lights ④ Cargo Release ⑤ Video

Loudspeaker: 15 W / 110 dBA / Effective range 100 m / Maximum range 200 m / Tilt adjustable 0° – 90°

Spotlight: 25 W / 1000 lm / 14° beam angle / Steady-on + Strobe / Brightness adjustable / Tilt adjustable 0° – 90°

Cargo Release: Dual hook, 5 kg per hook / Supports 2 firefighting bombs / Detonation height adjustable 1 – 20 m / Audible and visual status indication

Red & Blue Warning Lights: 2 modules (nose + under-fuselage), each with 4 red + 4 blue LEDs / 15 W / 16 flash patterns
