Aerial Fire Extinguishing Bomb Module (5kg / 10kg / 25kg)

Categories:

Contact Now
The Aerial Fire Extinguishing Bomb Module is a high-altitude explosive firefighting device specifically developed for forest fire prevention and aerial fire suppression operations. Featuring a durable PC + ABS composite impact-resistant shell, it combines high strength with shatter resistance for reliable performance under extreme conditions. Available in 5kg, 10kg, and 25kg variants, the module supports both dry powder and water-based extinguishing agents — including eco-friendly S-100-AB (-30°C) non-toxic, odorless agents and micro-nano composite ultra-fine dry powder — ensuring zero pollution to soil and air during deployment. With an automatic altitude-adjusted blast height (3–5 meters above flame surface), rapid response time of ≤2 seconds, and extensive coverage ranging from 15㎡ to 150㎡, this system delivers safe, efficient, and precise fire suppression for high-rise, forest, and industrial firefighting scenarios.

Specifications

Parameter 5kg  10kg  25kg
Product Name 5kg Aerial Fire Bomb 10kg Aerial Fire Bomb 25kg Aerial Fire Bomb
Agent Filling Volume Dry powder: 5kg / Water-based: 5L Dry powder: 10kg / Water-based: 9L Dry powder: 25–30kg / Water-based: 25L
Length 200mm 420mm 640mm
Max Outer Diameter 200mm 265mm 265mm
Coverage Area 15–20㎡ 40–80㎡ 100–150㎡
Spread Radius ≥ 2.5m ≥ 5m ≥ 10m
Safety Radius ≥ 10m ≥ 10m ≥ 15m
Agent Type Water-based: S-100-AB (-30°C) — non-toxic, odorless / Dry powder: Micro-nano composite ultra-fine dry powder
Operating Temperature -20°C ~ +55°C
Response Time ≤ 2s
Blast Height Automatic altitude adjustment (3–5m above flame surface), manual override available
Safety Configuration Excessive redundant security configurations
Shell Material PC + ABS composite impact-resistant material
Shelf Life 2 years
Applicable Scenarios Forest, high-rise, and industrial firefighting
